● Small and flexible, one machine with multiple functions, easy to operate, safe, comfortable, and easy to maintain
● Articulated frame, high-strength boom design, optimized structure, stable operation.
● Split detachable cab, panoramic view, double door design, comfortable and safe.
● Luochai's turbocharged engine has strong power and meets the national three emission standards.
● The joystick can be equipped with mechanical double handles, mechanical single handles, and pilot single handles, which are suitable for people with different operating habits.
Main Specification | |
Rated Load Capacity | 800kg-1000kg |
Operating Weight | 2800kg |
Bucket Capacity | 0.5m3 |
Bucket Width | 1400 mm |
Dimensions L*W*H | 5100x1400x2580 mm |
Lifting Height | 3200mm |
Dumping Height | 2800mm |
Engine | |
Model | Xinchai |
Rated Power | 36.8kw |
Rated Speed | 2200r/min |
Transmission | |
Type | Countershaft power shift |
Speed Gears | F2/R2 |
Axle | |
Front Axle | Fixed with calipers |
Rear Axle | Fixed with Osc.frame and calipers |
Brake System | |
Service Brake | oil Brake |
Parking Brake | Drum-type shoe brake,spring applied &air released |
Tires | |
Size | 12-16.5 or 31x15.5-15 |
Tread Pattern | As your request |
