● Small and flexible, one machine with multiple functions, easy to operate, safe, comfortable, and easy to maintain
● Articulated frame, high-strength boom design, optimized structure, stable operation.
● Split detachable cab, panoramic view, double door design, comfortable and safe.
● Luochai's turbocharged engine has strong power and meets the national three emission standards.
● The joystick can be equipped with mechanical double handles, mechanical single handles, and pilot single handles, which are suitable for people with different operating habits.
mance | Rated load | 1000KG |
Overall weight | 2900KG | |
Rated bucket capacity | 0.4 m3 | |
Overall dimension (L×W×H) | 4295*1680*2520mm | |
Maximum dump height | 2650mm | |
Minimum turning radius | 3800mm | |
Engine | Model | Xinchai/Yanmar 4 cylinder |
Type | lnline water cooled, four stroke | |
Rated power | 36.8/35 kw | |
Transmission system | Mode | Auto |
Maximum speed | 20 km/h | |
Drive axles | Mode | 4 WD |
Brake system | Service brake | Air brake |
Tyre | Front tyre pressure | 31*15.5-15 |
