● Small and flexible, one machine with multiple functions, easy to operate, safe, comfortable, and easy to maintain
● Articulated frame, high-strength boom design, optimized structure, stable operation.
● Split detachable cab, panoramic view, double door design, comfortable and safe.
● Luochai's turbocharged engine has strong power and meets the national three emission standards.
● The joystick can be equipped with mechanical double handles, mechanical single handles, and pilot single handles, which are suitable for people with different operating habits.
Performance | Rated load | 1600kg |
Overall weight | 3800kg | |
Rated bucket capacity | 0.8m3 | |
Maximum tractive force | 28KN | |
Maximum breakout force | ≥36.8KN | |
Maximum grade ability | 35℃ | |
Maximum dump height | 2370mm | |
Maximum dump reach | 800mm | |
Overall dimension (L×W×H) | 5240×1800×2600mm | |
Minimum turning radius | 5200mm | |
Engine | Model | Xichai498BT1(Euro III Standard ) |
Type | ln-line arrangement, water-cooled, four-cycle d iesel engine | |
Rated power | 36.8kw--2650r/min | |
Maximum torque | 9.8/1750 N. m/min | |
Min fuel-consume ratio | ≤230g/kw.h | |
Transmission system | Type | fixed-spindle power shift |
Torque converter | 265 | |
Gear shift | 2 forward shift 2reverse shift | |
shipf gear control oil pressure | P1.0-1.8MPa | |
Rated input speed | 2500(rpm) | |
Drive axles | Maximum speed | 25km/h |
model | isuzu axle | |
Wheel base (mm) | 2265mm | |
Wheel tread | 1520mm | |
Minimum ground clearance | 220mm | |
hydraulic system | System working pressure | 16MPa |
bucket lifting time | 4.7s | |
bucket falling time | 3.2s | |
total time for a signle working cycle | 9s | |
Brake system | Service brake | four wheel hydraulic spread-shed brake |
Parking brake | manual parking brake | |
Tyre | Service brake | 20.5/70-16 |
Front tyre pressure | 0.4Mpa | |
Rear tyre pressure | 0.35Mpa | |
optional | four more hydraulic line | |
quick hitch | ||
electric joystick | ||
adjustable steer wheel | ||
pallet fork | ||
hydraulic fork | ||
