Detail
• The hydraulic system has a dual-pump confluence with steering always in priority, reducing energy loss.
• 309° panoramic visibility gives the operator a very comfortable work environment in the cab.
• Fully-sealing and micro-pressuring system ensures the cab is clean and quiet.
• Single layer radiator and big range fin spacing for high efficiency and easy maintenance.
| SPECIFICATION | ||
| Performance | Rated load | 5000KG |
| Overall weight | 16500KG | |
| Rated bucket capacity | 3 m3 | |
| Maximum tractive force | 152KN | |
| Maximum breakout force | ≥170KN | |
| Overall dimension (L×W×H) | 8360*3050*3482mm | |
| Maximum grade ability | 30° | |
| Maximum dump height | 3150mm | |
| Maximum dump reach | 1250mm | |
| Minimum turning radius | 6640mm | |
| Engine | Model | Weichai Steyr WD10G220E23 |
| Type | lnline water cooled, four stroke | |
| No. of cylinder-bore/stroke | 6－126×130mm | |
| Rated power | 162kw | |
| Maximum torque | 960N.m | |
| Min fuel-consume ratio | ≤215g/kw.h | |
| Transmission system | Torque converter | ZL50 |
| Gearbox mode | Planetary | |
| Gear shift | 2 forward shift ,1 reverse shift | |
| Maximum speed | 38km/h | |
| Drive axles | Main reducing spiral | bevel gear grade 1reduction |
| Decelerating mode | Bevel gear grade I reduction | |
| Wheel base (mm) | 3340mm | |
| Wheel tread | 2250mm | |
| Minimum ground clearance | 460mm | |
| Hydraulic system | System working pressure | 18MPa |
| Boom lifting time | 5.95+0.2s | |
| Total time | 10.95+0.5s | |
| Fuel tank capacity | 300L | |
| Function of leveling automatically | Yes | |
| Brake system | Service brake | Air assist disc brake on 4 wheels |
| Parking brake | Manual parking brake | |
| Type specification | 23.5-25 | |
| Tyre | Front tyre pressure | 0.4Mpa |
| Rear tyre pressure | 0.35Mpa | |
