SHS50 Stationary Concrete Batching Plant

share
copy Link
Facebook
X
LinkedIn
Productivity 50m3/h
Capacity of Mixer 1.0m3
Discharge Height 3.8m
Feeding Type Skip Hopper
Whatsapp
Message
Detail

1. The Description of SHS50 Concrete Batching Plant:

HZS50 series concrete batching plant(concrete mixing plant) belongs to compulsory and efficiency equipment, which can produce various kinds of concrete including quaking concrete and hard concrete.

2. Short Features of SHS50 Concrete Batching Plant:

1).It is widely used on small and medium scale building project, road and bridge projects . It’s also an ideal equipment to produce commercial concrete.

2). The main mixer of this series concrete batching plant use JS series twin-shaft concrete mixer which is very reliable.

3). It can be operated and maintained conveniently through high technology control system with the newest design concept.

4).Saving space

5).Cost-effective choice



Specification

Unit

Value

Productivity

m3/h

50

Capacity of Mixer

m3

1

Discharge Height

m

3.8

Aggregate Bin

Quantity

3

Capacity of Aggregate Bin

m3

10

Max. Weighing Value of aggregate

kg

3000

Max. Weighing Value of cement

kg

600

Max. Weighing Value of water

kg

400

Max. Weighing Value of additive

kg

50

Feeding Type

/

Skip Hopper

Cement Silo

/

Optional

Cement Screw Conveyor

/

Optional

Control Mode

/

Auto/Semi control
