1. The Description of SHS35 Concrete Batching Plant:
HZS35 concrete batching plant features a full-automatic control concrete batching plant which is composed by feeding, batching, mixing, electrical control and steel structure components. It’s widely used in road, bridge, dam, railway, highway, etc..
2. Short Features of SHS35 Concrete Batching Plant:
1). Stability and Durability: adapt and apply the most advanced technologies around the world;
2). Stationary modular compact structure, fast and easy installation.
3). Excellent mixing performance with high efficiency and high productivity
4).Excellent environmental protection, dust collection system and anti-noise design.
5). Easy operation
Specification | Unit | Value |
Productivity | m3/h | 35 |
Capacity of Mixer | m3 | 0.75 |
Discharge Height | m | 3.8 |
Aggregate Bin | Quantity | 3 |
Capacity of Aggregate Bin | m3 | 8 |
Max. Weighing Value of Aggregate | kg | 2250 |
Max. Weighing Value of Cement | kg | 450 |
Max. Weighing Value of Water | kg | 300 |
Max. Weighing Value of Additive | kg | 75 |
Feeding Type | / | Skip Hopper |
Cement Silo | / | Optional |
Cement Screw Conveyor | / | Optional |
Control Mode | / | Auto/Semi control |
